Equivalent Grades :

Equivalent Grades Exporter

Contact Us For High Quality Equivalent Grades

At JB Steel we pride ourselves on always putting the customer first. We help make stainless solutions simple for you by ensuring satisfaction through high delivery performance, flexibility and extensive service.

We are pleased to introduce ourselves as one of the leading Importsers, Exporters, Suppliers & Stockists of Equivalent Grades.

We would appreciate to get your esteemed enquires and look forward to the pleasure receiving your valuable response.

Equivalent Grades
ALLOY STEEL

Equivalent Grades
Internal Standard BS DIN IS EN SAE/AISI
EN18 530A40 37Cr4 40Cr1 EN18 5140
EN24 817M40 34CrNiMo6 40NiCr4Mo3 EN24 4340
EN19C 709M40 - 40Cr4Mo3 EN19C 4140,4142
EN19 709M40 42Cr4Mo2 40Cr4Mo3 EN19 4140,4142
EN18D 530A40 37Cr4 40Cr1 EN18D 5140
EN18C 530A40 37Cr4 40Cr1 EN18C 5140
EN353 815M17 - 15NiCr1Mo12 EN353 -
EN18A 530A40 37Cr4 40Cr1 EN18A 5140
EN354 820M17 - 15NIVCr1Mo15 EN354 4320
27C15 - 28Mn6 27C15 - 1527
20MnCr5 - 20MnCr5 20MnCr1 - -
20Mn2 150M28 - 20Mn2 EN14A 1524
16MnCr5 - 16MnCr5 17Mn1Cr95 - 5120
15Cr3 523A14 15Cr3 15Cr65 EN206 5015
FILESTEEL - - - - -
EN18B 530A40 37Cr4 40Cr1 EN18B 5140
SCM420 708M20 - - - -
SAE8620 805M20 - 20NiCrMo2 EN362 SAE8620

CARBON STEEL

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI JIS
EN15B 150M36 36Mn5 37Mn2, 37C15 EN15B 1536 -
EN32B - CK15 C14 EN32B 1015,1016,1018 -
SAE1038 - CK38 - - 1038 -
EN43C - - C50 EN43C 1050 -
CK45 - CK45 45C8 1045 - -
EN9 070M55 CK55 C55 EN9 1055 -
C35 - C35 35C8, C35Mn75 - 1035 -
EN42 - CK75 80C6 EN42 1074 -
EN42B - C67 65C6 EN42B 1065 -
EN43 080M50 C55 60C6 EN43 1055 -
EN43B 080A47 CK45 - EN43B 1045 -
SAE1541 150M36 36Mn7 37C15 EN15,15A SAE1541 SMn438
EN8 080A40 CK45 45C8 EN8 1040,1045 -
EN8A 080A40 CK45 45C8 EN8A 1040,1045 -
EN8B 080A40 CK45 45C8 45C8 1040,1045 -
EN8C 080A40 CK45 45C8 EN8C 1040,1045 -
EN8D 080A40 CK45 45C8 EN8D 1040,1045 -

HIGH CARBON STEEL

Internal Standard Equivalent Grades
EN SAE/AISI JIS***
PC77 - 1075 SWRH77B
PC80 - 1080 SWRH82B
PC80CR - 1080 SWRH82B
PC270K - 1080 SWRH82B
PC270KCrV - 1080 SWRH82B
R30 EN5D 1030 SWRH32B
R35 - 1035 SWRH37B
R40 EN8 1040 SWRH42B
R45 EN43B 1045 SWRH47B
R50 - 1050 SWRH52B
R55 EN9 1055 SWRH57B
R60 EN43D 1060 SWRH62B
R65 EN42B 1065 SWRH67B
R70 - 1070 SWRH72B
R75 - 1075 SWRH77B, SUP3
R80 - 1080 SWRH82B
R80M - 1085 SWRH87B
R95 - 1090 3CD95A

SPRING STEEL

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI JIS
60Si7 - 60Si7 60Si7 EN45A - -
SUP7 - 59Si7 - EN45A 9260 SUP7
SUP12V 685A57 54SiCr6 - - 9254 SUP12V
55Si7 - 55Si7 55Si7 EN45A - -
EN45 250A53 55Si7 55Si2Mn90 EN45 9255 -
65Si7 - 65Si7 - EN45A 9260 -
EN45A 250A58 - - EN45A 9260 -
50CrV4 735A51 50CrV4 50Cr4V2 EN47 6150 SUP10
SAE9254 - - - - 9254 -
SUP7N - - - - 9260 SUP7N
SUP11A - - - - 51B60 SUP11A
SUP9 - 55Cr5 - - 5155 SUP9

BEARING QUALITY STEEL

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI
SAE52100 534A99/535A99 100Cr6 103Cr1 EN31 SAE52100
EN31M 534A99/535A99 100Cr6 103Cr1 EN31M 52100
EN31 534A99/535A99 100Cr6 103Cr1 EN31 52100

COLD HEADING QUALITY STEEL - CHQ

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI JIS
SAE1020CHQ 070M20 CK22 C20 EN 3A SAE1020 SWRCH20A
SAE1022CHQ - - - - SAE1022 -
SAE4140CHQ 709M40 42CrMo4 40Cr4Mo3 EN19 SAE4140 SCM440
SAE1018CHQ - H111 C-15Mn75 EN2C SAE1018 -
SAE1541CHQ 150M36 36Mn7 37C15 EN15,15A SAE1541 SMn438
15B41 - - - - 15B41 -
1045CHQ - CK45,C45 45C8,C45 - 1045 -
SAE1015CHQ - CK15 - EN32B SAE1015 -
1038CHQ - CK38 - - 1038 -
SAE1012CHQ 040A12 CK10 C7, C10 2A/1,2B SAE1012 SWRCH12A
15B25 - - 26C10BT - 15B25 -
SAE1010CHQ - CK10 C10 - SAE1010 -
10B21 - - 21C10BT - 10B21 -
SAE1008CHQ 040A04 C10 C5 2A,2A/1,2B SAE1008 SWRCH8A

FREE CUTTING STEEL

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI JIS
EN15(AM) 216M36 - 40Mn15S12 ENI5(AM) 1137 -
EN1A 220Mo7 9SMn28 11C10S25 EN1A 1213 SUM22
EN1APB 220Mo7Pb 9SMnPb36 - EN1APB 12L14 SUM24L
EN8M 212M36 - 40C10S18 EN8M 1I46 -
SAE1146 - - 40C10S18 EN8M SAE1146 -

LOW CARBON STEEL

Internal Standard Equivalent Grades
BS DIN IS EN SAE/AISI JIS
LCCF 040A04 C10 CS 2A, 2A/1, 2B SAE1008 SWRCH8A
SAE1015 - CK15 - - SAE1015 -
SAE1012 040A12 CK10 C7, C10 2A/1, 2B SAE1012 SWRCH12A
SAE1010 - CK10 C10 - SAE1010 -
SAE1008 040A04 C10 C5 2A, 2A/1, 2B SAE1008 SWRCH8A
SAE1020 070M20 CK22 C20 EN 3A SAE1020 SWRCH20A
P12 - - - - - -
SAE1018 - CK15 C15Mn75 EN32B,EN32C SAE1018 -

MATERIAL CROSS REFERENCE LIST

CARBON STEEL
USA Japan Germany U. K. France Italy Spain Sweden China
AISI/SAE JIS W.-nr. DIN BS EN AFNOR UNI UNE SS GB
A570.36 STKM 12A
STKM 12C
1.0038 RSt.37-2 4360 40 C E 24-2 Ne 1311 15
1015 1.0401 C15 080M15 CC12 C15, C16 F.111 1350 15
1020 1.0402 C22 050A20 2C CC20 C20, C21 F.112 1450 20
1213 SUM22 1.0715 9SMn28 230M07 1A S250 CF9SMn28 F.2111
11SMn28
1912 Y15
12L13 SUM22L 1.0718 9SMnPb28 S250Pb CF9SMnPb28 11SMnPb28 1914
1.0722 10SPb20 10PbF2 CF10Pb20 10SPb20
1215 1.0736 9SMn36 240M07 1B S300 CF9SMn36 12SMn35 Y13
12L14 1.0737 9SMnPb36 S300Pb CF9SMnPb36 12SMnP35 1926
1015 S15C 1.1141 Ck15 080M15 32C XC12 C16 C15K 1370 15
1025 S25C 1.1158 Ck25 25
A572-60 1.890 StE380 4360 55 E FeE390KG 2145
1035 1.0501 C35 060A35 CC35 C35 F.113 1550 35
1045 1.0503 C45 080M46 CC45 C45 F.114 1650 45
1140 1.0726 35S20 212M36 8M 35MF4 F210G 1957
1039 1.1157 40Mn4 150M36 15 35M5 40Mn
1335 SMn438(H) 1.1167 36Mn5 40M5 36Mn5 2120 35Mn2
1330 SCMn1 1.1170 28Mn6 150M28 14A 20M5 C28Mn 30Mn
1035 S35C 1.1183 Cf35 060A35 XC38TS C36 1572 35Mn
1045 S45C 1.1191 Ck45 080M46 XC42 C45 C45K 1672 Ck45
1050 S50C 1.1213 Cf53 060A52 XC48TS C53 1674 50
1055 1.0535 C55 070M55 9 C55 1655 55
1060 1.0601 C60 080A62 43D CC55 C60 60
1055 S55C 1.1203 Ck55 070M55 XC55 C50 C55K 55
1060 S58C 1.1221 Ck60 080A62 43D XC60 C60 1678 60Mn
1095 1.1274 Ck101 060A96 XC100 F.5117 1870
W1 SK3 1.1545 C105W1 BW1A Y105 C36KU F.5118 1880
W210 SUP4 1.1545 C105W1 BW2 Y120 C120KU F.515 2900
